Max Splitting Force | 15T | 20T |
Cycle Time | 7seconds | 8seconds |
Max Splitting Length | 610mm | 610mm |
Max Splitting Diameter | 380mm | 400mm |
Work Efficiency | 4m3/h | 5m3/h |
Power | 15HP gasoline engine | 15HP gasoline engine |
Engine Displacement | 420cc | 420cc |
Fuel Tank Capacity | 6.5L | 6.5L |
Engine Oil Capacity | 1.1L | 1.1L |
Gross Torque | 25N.m/2500rpm | 25N.m/2500rpm |
Length:3.2m | Length:3.2m | |
Width of belt:250mm | Width of belt:250mm | |
Width of chute:400mm | Width of chute:400mm | |
Hydraulic rotator:1set | Hydraulic rotator:1set | |
Chain Saw length | 1.2m | 1.2m |
Chain Saw Rotate Speed | 5600rpm | 5600rpm |
Sawing Speed | Adjustable | Adjustable |
Oil Pump | 22GMP, 2-stage | 22GMP, 2-stage |
Oil Tank Capacity | 50L | 50L |
Control Valve | ONE-handle 4-Directional control valve | ONE-handle 4-Directional control valve |
Tyre | 12" | 12" |
Knife | 4 ways (6 ways option) | 4 ways (6 ways option) |
Weight | 480kg | 510kg |
Main Machine Package size | 2200x900x1100mm | 2200x900x1100mm |
Conveyor Package Size | 2260*960*1170mm | 2260*960*1170mm |
Units/20’: | 12Units | 12Units |
